Application (Please consult your owner's manual for your application fitment type):
ALL
8th Generation Accord 2008+ ONLY
2 and 4
rings.
Product Description (may describe some optional equipment) :
2 or 4 Halos
1 full wiring harness
Lifetime Warranty
Online Instructions
All Hardware and Installation Included
Engineering Detail:
Requires baking of the headlights (20 minutes @ 200 degrees on cookie sheet and bake)
30-50 minute complete install using standard hand tools per side.
36000mcd or 2X as bright as the nearest competitor.
Mounting clips
Benefits:
Updated Look
Allows you to clear or black out your turn signal at the same time
Can be wired as DRL (daytime running lights)
Significant improvement in visual appeal of car
Install Tips:
PRETEST the bulbs, do not flex the bulbs in any way.
Mount the controller UNDER the headlights on a flat, dry and vibration free surface
Ensure secure connections to and from the headlight.
1) Remove bolt from fender liner in the wheel well. 2) Remove bolt holding bumper edge just inside peeled back fender liner. 3) Remove all the bolts at the bottom of the bumper 4) Remove 5 pins from the top of the bumper 5) remove bumper. 6) Remove fender bolts holding lights 7) Remove top 2 bolts holding lights 8) Disconnect as many connections as possible prior to... 9) Pulling light out 10) Cookie sheet for 20 minutes at 200 degrees 11)
Remove 4 screws holding back of light against front of light plexiglass, gently slide plastic tabs off the front plexiglass while doing this.
12) Remove inner beauty trim's 2 screws.
13) Place rings at respect corners - 1 dap of glue - less than an teardrop worth at the corners of the rings and the bottom of the ring center. 14) Insert ring
bottom FIRST, then push gently tops of rings onto beveled edge of trim piece. 15) Hold for 2-3 minutes (use QUICKGRIP for best results) 16) Wait 10 minutes for glue to fully set. 17) Push wires out the back of high beam and low beams respectively, remove the rubber caps frist, then seal rubber caps OVER the wires. 18) Put back into oven for 5 minutes, seal up headlight and re-insert all screws. 19) Attach black connectors. 20) Finish Install by reattaching all body parts.
21) YOU ARE DONE SEE LINK BELOW FOR ADDITIONAL PICS
