Wifi RGB Color Shift Wireless Controller
Title:
The Umnitza Multifunction WiFi RGB LED Remote is the latest addition to our line of intelligent LED controllers.
This device uses WiFi technology which makes full control of your LED products easily advantageous. No more
constant fiddling with wired controllers, the WiFi controller gives you over 160ft. wireless range of your
indoor LED products and over 320ft of your outdoor LED products. Also, with this device you can control
your LED products with your Smart Phone! The software provided, gets you easily connected whether you
are an Android or IOS user.
This controller is specially desined for controlling a variety of LED Lighting.
For example like RGB Flex LED Lighting Strips, wall washer lights, panel lights, etc.
Easy to connect, easy to use features such as jump changing, gradual changing, strobe, flash as well as other modes.
Android/IOS compatible.
Product Includes:
LED-WiFi Controller Module
RF remote control (AAA Batteries Included)
Install disc which has both versions of latest IOS(7.0) and Android(4.0) operating systems for smart phone control.
NOTE* Some of the latest versions of the Android Operating system (4.4 or KitKat)are currently not compatible
with the application. Keep checking the Google Play store for an updated App.
RF Controller Specs:
Has a high precision touch control chip, that increases touch sensitivity and reduces mistaken triggers.
Working temperature: -20-60C
Power supply method: AAA*3
Supply voltage: 1.5 Volts per channel/3 channels
Standby power: 0.015mW
Standby current: 3uA
Working current: 200uA
Emission current: 10mA
Remote control distance: approximately 164ft
Weight: 2.0oz
Height: 0.9in
Length: 4.4in
Width: 2.2in
Wifi Module Specs:
Working voltage: DC5~24V
Output control: can control 3 channel, 2 channel, or 1 channel LED devices
Wireless Sensitivity: 802.11b DSSS(-5dBm),802.11b CCK (-10dBm),802.11g OFDM(-15dBm)
Output current: 4 Amps/3 Channels
Connect mode: common anode
Weight: 9.6oz
Height: 1.3in
Length: 4.9in
Width: 3.4in
